Cambridge EXA100 Integrated Stereo Amplifier

Best-in-Class Sound: Amplifier tech inspired by our flagship Edge M monobloc delivers an incredibly wide, detailed soundstage. Be moved by your music like never before.

Power With Control: 100 Watts per channel of perfectly tuned Class AB amplification skilfully drives even the most demanding speakers with ease.

Digital Connectivity: Get your TV, CD, USB drives and more connected via HDMI eARC, TOSLINK, Coaxial & USB Audio digital inputs

Balanced XLR Inputs: Enjoy the best possible analogue sound quality with these premium analogue connections.

ESS ES9018K2M SABRE32 DAC: For exceptional digital-to-analogue conversion; tuned in London like no other for peak performance.

Bluetooth aptX HD: Wirelessly connect devices such as the Alva TT V2 turntable and stream in glorious hi-def quality.

Power Amp Mode: For use with a dedicated preamp or as part of a multi-channel system.

Dual Speaker Zones: Why limit the fun to just one room? Two sets of speaker outputs offer a second zone option.



Technical Specifications

Power Output

100W RMS into 8 Ohms @ <1%THD+N, 155W RMS into 4 Ohms @ 1kHz <1%THD+N

Amplification Class-A/B

DAC ES9018K2M

Preamp Mode Yes

Frequency Response <3Hz – >40kHz +/-1dB

Toroidal Transformer Yes

Bi-wiring possible Yes

Analogue RCA Inputs 4 pairs

Balanced XLR Input 1 pair

S/PDIF TOSLINK Input 2

S/PDIF Coaxial Input 1

Asynchronous USB Input

USB Type B conforming to USB Audio Class 1 or USB Audio Class 2 (user selectable)

Bluetooth 5.0 aptX HD

HDMI ARC Input 1 (eARC compatible)

Preamp Output RCA pre-out

Headphone Output Yes

Subwoofer Output 1 x RCA

Speaker Outputs Yes

S/PDIF TOSLink Optical TOSLINK: 16/24-bit 32-96kHz

S/PDIF Coaxial Coax SPDIF: 16/24-bit 32-192kHz

HDMI eARC PCM up to 24bit/192kHz

USB Audio

USB Audio Class 1: Up to 24-bit 96kHz (asynchronous) | USB Audio Class 2: Up to 24-bit 384kHz (asynchronous) and up to DSD-256

Bluetooth 5.0 A2DP/AVRCP supporting SBC, aptX and aptX HD codecs

RS232 Control Yes

THD (Unweighted)

<0.002% 1kHz at 80% of rated power (8 Ohms) | <0.02% 20Hz – 20kHz at 80% of rated power

S/N Ratio (REF 1W) >91 dB

Crosstalk @1kHz >90

Input Sensitivity

Input A2-A4 (unbalanced) 395mV RMS

Input Impedances

Input A1 (balanced) 100 kOhm Input A2-A4 (unbalanced) 45 kOhm

Power Amp Damping Factor >160 at 1kHz

Subwoofer Output 1 x RCA

Max Power Consumption 1200w

Standby Power Consumption <0.5W

Dimensions (W x H x D) 115 x 430 x 341mm (4.5 x 16.9 x 13.4”)

Weight 12.8kg (28.2Lbs)

In the box

Power cords, Remote control, Welcome letter, Registration Card, Safety guide
